Standard size of outrigger pad:
| Size ( square ) | Weight ( kg ) | Weight Load ( kg/pad ) |
| 400 x 400 x 40 mm | 6.3 | 12,000 |
| 500 x 500 x 40 mm | 9.9 | 15000 |
| 600 x 600 x 40 mm | 14.2 | 20000 |
| 600 x 600 x 50 mm | 18.0 | 25000 |
| 600 x 600 x 60 mm | 21.2 | 30000 |
| 800 x 800 x 40 mm | 25.3 | 35000 |
| 800 x 800 x 50 mm | 31.3 | 40000 |
| 800 x 800 x 60 mm | 38.4 | 45000 |
| 1000 x 1000 x 50 mm | 48.0 | 50000 |
| 1000 x 1000 x 60 mm | 58.0 | 70000 |
| 1200 x 1200 x 60 mm | 85.0 | 110000 |
| 1200 x 1200 x 80 mm | 115.0 | 120000 |
| 1200 x 1200 x 100 mm | 141.0 | 160000 |
| 1500 x 1500 x 100 mm | 210.0 | 200000 |
| 2000 x 1000 x 100 mm | 196.0 | 220000 |
| 3000 x 1000 x 100 mm | 588.0 | 300000 |
| Size ( round ) | Weight ( kg ) | Weight Load ( kg/pad) |
| 800*50 mm | 25.0 | 35000 |
| 800 x 60 mm | 30.0 | 40000 |
| 900 x 50 mm | 30.0 | 45000 |
| 900 x 60 mm | 35.0 | 50000 |
| 1000 x 60 mm | 40.0 | 60000 |
| 1000 x 80 mm | 61.5 | 80000 |
| 1200 x 60 mm | 66.4 | 90000 |
| 1200 x 80 mm | 88.5 | 120000 |
| 1500 x 100 mm | 180.0 | 180000 |
Performance of UHMWPE Outrigger Pads:
1. Wear resistance ranks first among plastics, 4 times higher than nylon 66 and polytetrafluoroethylene, and 6 times higher than carbon steel:
2. The impact strength ranks first among plastics, twice that of PC and five times that of ABS, and can maintain extremely high toughness at liquid nitrogen temperature (-196 ° C)
3. The self-lubricating properties are comparable to polytetrafluoroethylene, with a friction coefficient of only 0.07-0.11
4. The impact energy absorption value is the highest among all plastics, and the noise reduction effect is very good;
5. The chemical stability is very high, and it can withstand the effects of various corrosive media and organic media within a certain temperature and concentration range.
