UHMWPE Crane Outrigger Pad HDPE Block for Support


Standard size of UHMWPE Crane Outrigger Pad HDPE Block for Support:

Size ( square )Weight ( kg )Weight Load ( kg/pad )
400 x 400 x 40 mm
6.312,000
500 x 500 x 40 mm
9.915000
600 x 600 x 40 mm
14.220000
600 x 600 x 50 mm
18.025000
600 x 600 x 60 mm
21.230000
800 x 800 x 40 mm25.335000
800 x 800 x 50 mm
31.340000
800 x 800 x 60 mm
38.445000
1000 x 1000 x 50 mm
48.050000
1000 x 1000 x 60 mm
58.070000
1200 x 1200 x 60 mm
85.0110000
1200 x 1200 x 80 mm
115.0120000
1200 x 1200 x 100 mm
141.0160000
1500 x 1500 x 100 mm
210.0200000
2000 x 1000 x 100 mm
196.0220000
3000 x 1000 x 100 mm
588.0300000
Size ( round )Weight ( kg )Weight Load ( kg/pad)
800*50 mm
25.035000
800 x 60 mm
30.040000
900 x 50 mm
30.045000
900 x 60 mm
35.050000
1000 x 60 mm
40.060000
1000 x 80 mm
61.580000
1200 x 60 mm
66.490000
1200 x 80 mm
88.5120000
1500 x 100 mm
180.0180000

WHY ARE OUTRIGGER PADS NEEDED?

They provide effective support to machinery and vehicles that use stabilisers or outrigger feet on terrain where load bearing and spreading capacity is an issue, such as soft ground and sensitive flooring or terrain.

Without their use, outriggers and stabilisers can potentially puncture the ground or damage paved surfaces, causing a serious accident if the equipment topples over and considerable cost to recover.

HOW DO THEY WORK?

Stable support is achieved by spreading the load from the stabiliser or outrigger foot over the large and tough surface of an outrigger pad or crane mat. The overall pressure on the ground is reduced by applying the load over a wider surface area, and effectively supporting the machinery or vehicle. Our range of outrigger pads are durable yet lightweight, making them safe and easy to handle.

Outrigger pads offer a wide variety of products covering most applications, with vertical load bearing capacities from 5 to 350 tonnes and prices to suit all budgets.
